Model No: One Die Two Blow Cold Heading Machine

15-63G Screw Cold Forming Machine

Quantity :
Contact Now
Specification Parameters


One Die Two Blow Cold Heading Machine

Item

Machine Model

15-30G

15-37G

15-50G

15-63G

15-76G

15-100G

Blank Diameter mm

2.3-5

2.3-5

2.3-5

2.3-5

2.3-5

2.3-5

Blank Length mm

6-30

6-37(40)

6-50

6-63

6-76

75-100(110)

Main Mold
mm

34.5x55

34.5x55

34.5x67

34.5x80

34.5x100

34.5x120

Punch 1st (mm)
Punch 2nd (mm)

31x73

31x73

31x73

31x73

31x73

31x73

Cutting mold mm

19x35

19x35

19x35

19x35

19x35

19x35

Cutter
mm

10x32x63

10x32x63

10x32x63

10x32x63

10x32x63

10x32x63

Main Motor
KW

3KW/380V

3KW/380V

3KW/380V

3KW/380V

3KW/380V

3KW/380V

Pump
KW

0.33

0.33

0.33

0.33

0.33

0.33

Capacity PCS/min

260-300

220

190

140

130

90

Weight
KG

2,300

2,300

2,300

2,300

2,300

2,300

Automatic Detection Machine

Selectable

Selectable

Selectable

Selectable

Selectable

Selectable

Screw Feeding Machine

Selectable

Selectable

Selectable

Selectable

Selectable

Selectable

IVITAL GROUP Cold Heading Machine, the cutting-edge technology in screw manufacturing. As a leading manufacturer in China,

IVITAL GROUP takes pride in providing efficient and reliable solutions for the fastener industry. The IVITAL GROUP Cold Heading

Machine is designed to produce a wide range of screws, including standard and non-standard parts. IVITAL GROUP One Die Two

Blow Machine, the machine is capable of creating various types of screws with precision and speed.

The IVITAL GROUP Screw Cold Heading Machine offers a versatile solution for fastener production. It can manufacture a wide

array of screws, including drywall screws, self-drill screws, blind rivets, flat head screws, wood screws, screw nuts, roof screws,

screw nails, self-tapping screws, drywall board screws, countersunk head screws, and auto screws. From standard parts to

customized designs, this machine is equipped to meet the diverse needs of the fastener industry. With its advanced technology

and high efficiency, the IVITAL GROUP Cold Heading Machine provides a reliable and cost-effective solution for screw manufacturing.

The IVITAL GROUP Cold Heading Machine stands out as the go-to choice for businesses seeking a superior solution for screw

production. With its ability to produce a wide range of screws with precision and consistency, this machine offers unparalleled

performance in the industry. Whether it's for small-scale production or large-scale manufacturing, the IVITAL GROUP Screw Cold

Heading Machine is designed to meet the demands of fastener production with efficiency and quality. From the production of

standard screws to non-standard parts, this machine is capable of delivering exceptional results for all types of fasteners.

In summary, the IVITAL GROUP Cold Heading Machine is the ultimate solution for fastener manufacturing. With its advanced

technology, efficient production process, and versatility in creating various types of screws, this machine sets a new standard in the

industry. As a reliable and high-tech machine from IVITAL GROUP, it offers businesses a competitive edge in the fastener market.

Experience the power of precision and efficiency with the IVITAL GROUP Cold Heading Machine, the leading choice for screw

making machines.
